Scope
It is widely used in rice transplanters, construction machinery, generator sets, plant protection machinery, tractors and other supporting fields.
Main Technical Parameters
Model | 3M78 | M403TC | M403TCI | |
Type | Inline, water-cooled, four-stroke | |||
Number of cylinders | 3 | |||
Cylinder diameter | 78 | |||
Stroke | 85 | |||
Total displacement | 1.218 | |||
Rated net power/speed | 18.4/2600 | 25.8/2600 | 25.8~35/2600~3200 | |
Maximum net torque/speed | 82/1820 | 118/1820 | 139~145/1680~2240 | |
Fuel system | High voltage common rail | |||
Air intake mode | Naturally aspirated | Supercharge | Turbo intercooling | |
Net mass (kg) | 115 | 125 | ||
Dimensions (L x W x H) | 526×483×640 | 526×483×675 | ||
Emission phase | Non-road countries IV and EU V stages | / | Non-road national IV | |
