Model/ | T25 | T35 |
Engine type | Single-cylinder, horizontal, evaporative water-cooled, four-stroke | |
Combustion chamber type | Direct injection | |
Cylinder diameter (mm) | 115 | 130 |
Stroke (mm) | 120 | 125 |
Displacement (L) | 1.246 | 1.659 |
Calibrated Power (kW) | 18 | 24 |
Calibration speed (r/min) | 2300 | 2300 |
Maximum torque (N.m) | ≥83.7 | ≥111.6 |
Maximum torque point speed (r/min) | ≤1840 | ≤1840 |
Idle speed (r/min) | ≤800 | ≤800 |
Starting mode | Hand or electric start | |
Net mass (kg) | 190 | 224 |
Overall dimensions [L×W×H (mm)] | 858×450×699 | 916×475×709 |
Product Features：
1. Optimize the fuel system, reasonably organize the combustion in the cylinder, and greatly improve the economy of diesel engine.
2. Adopt nitriding gears to improve the reliability of diesel engines.
3. Use high-quality rolling bearings to improve the bearing capacity.
Scope of Application：
Compared with ZS-series and L-series, the speed and power have been improved, and the power is more sufficient. It is especially suitable for matching tractors, three-wheeled vehicles, etc.
