Model/Items | ZR175 | ZR180 | L12 | H14 | H16 | L18 | ZS1105 | H20 | L24 | L28 | L32 | EH36 | HS400 |
Engine type | Single-cylinder, horizontal, evaporative water-cooled, four-stroke | ||||||||||||
Combustion chamber type | Direct injection | ||||||||||||
Cylinder diameter (mm) | 75 | 80 | 90 | 95 | 100 | 100 | 105 | 105 | 115 | 125 | 130 | 135 | 135 |
Stroke (mm) | 80 | 80 | 95 | 98 | 100 | 120 | 115 | 120 | 120 | 120 | 125 | 125 | 145 |
Displacement (L) | 0.353 | 0.402 | 0.604 | 0.694 | 0.785 | 0.942 | 0.996 | 1.039 | 1.246 | 1.473 | 1.659 | 1.789 | 2.076 |
Calibrated Power (kW) | 4.85 | 5.67 | 8.8 | 9.7 | 11.5 | 12.7 | 13.2 | 14.7 | 17 | 20 | 23 | 25 | 27 |
Calibration speed (r/min) | 2600 | 2600 | 2400 | 2400 | 2400 | 2200 | 2200 | 2300 | 2200 | 2200 | 2200 | 2200 | 2200 |
Maximum torque (N.m) | / | ≥39.2 | ≥43.2 | ≥51.3 | ≥61.7 | ≥64 | ≥68.4 | ≥82.6 | ≥97.2 | ≥111.8 | ≥121.5 | ≥131.3 | |
Maximum torque point speed (r/min) | / | ≤1920 | ≤1760 | ||||||||||
Idle speed (r/min) | ≤1000 | ≤900 | ≤800 | ||||||||||
Starting mode | Hand or electric start | ||||||||||||
Net mass (kg) | 70 | 72 | 101 | 110 | 120 | 165 | 165 | 170 | 190 | 220 | 224 | 224 | 265 |
I. Product Features:
1. Low fuel consumption: Strengthen the fuel system, adopt a new high-pressure fuel injection pump and P-type fuel injector, optimize the combustion process, save energy and have low emissions.
2. Large torque reserve: reaching more than 20%, strong climbing ability.
3. High reliability: Optimize the structural strength of parts and adopt a number of new technologies (laser quenching, ceramic infiltration gas ring, powder metallurgy valve seat), the product is wear-resistant and sealed, and prolongs life.
4. Easy starting: the diesel engine can be started directly without pulling the throttle; The starting smoke is low and the idle speed is smooth.
5. Low vibration and noise: Optimized balance system, low vibration and low noise.
6. Good interchangeability: the installation dimensions and overall dimensions are the same as those of traditional products. It is convenient for users to upgrade.
II. Scope of Application：
tricycles, tractors, construction machinery, water pump units, generator units and other various fields.
