Main Technical Parameters
3G25TC | 4L88 | 4G33TC | 4G33V16 | 4G36V16 | |||
Engine type | Inline water-cooled four-stroke | ||||||
Number of cylinders | 3 | 4 | 4 | 4 | |||
Cylinder diameter | 95 | 95 | 95 | 98 | |||
Stroke | 115 | 100 | 115 | 120 | |||
Total displacement | 2.445 | 2.834 | 3.261 | 3.62 | |||
Number of valves/cylinder | 2 | 2 | 2 | 4 | 4 | ||
Rated net power/speed | 40.5~58.8/2300~2400 | 44.2~66.2/2300~2600 | 51.5~78/2300~2600 | 62.6~96/2300~2600 | 92~108/2300~2600 | 110~128/2300~2600 | |
Maximum net torque/speed | 305/1580~1780 | 358/1510~1710 | 415/1510~1710 | 454/1580~1780 | 560/1510~1710 | 565/1510~1710 | |
Fuel system | High voltage common rail | ||||||
Air intake mode | Turbo intercooling | ||||||
Post-conditioning | DPF | DPF | DPF | DPF或DOC+DPF | DPF或DOC+DPF | DOC+SDPF | |
Net mass (kg) | 255 | 260 | 270 | 280 | 320 | ||
Dimensions (L x W x H) | 523×530×787 | 702×593×724 | 740×614×798 | 830×825×845 | 830×825×865 | ||
Emission phase | Non-road national IV | Non-road national IV | Non-road countries IV and EU V stage | Non-road national IV | Non-road national IV | ||
